D Series
INDOOR LED
Overview
The D Series is a more economical indoor LED video solution, packed with many features and SMD LED Diode Technology. It is ideal for just about any indoor situation where you need a large digital display. It is very popular for houses of worship, retail, corporate spaces, and financial institutions.
Size Available: 3.15×31.57×0.20 ft (960×480×61 mm)
- ULTRA LIGHT
- SMART MODULE
- FAST ASSEMBLY
- FRONT ACCESS
- HIGH GRAY SCALE
- IP65
HDR & High Refresh Rate
The system data is processed in depth, and the HDR high dynamic picture is finely tuned for low-brightness and high gray scale. This enhances the layering of the dark and bright pictures, making the images more realistic and the colors more vivid. Also features anti-gamma correction technology, and a 3840Hz high refresh rate.
High Gray Scale at Low Brightness
The use of high-quality LED lamps and the high-end constant current source of the PWM LED Driver, makes the LED display screen color reproduction and low gray details more prominent. This is very important in preventing color and picture degradation at low brightness.
Traditional LED
D Series
Easy Installation & Maintenance
The back of this product features an IP65 fully enclosed cabinet, which allows for a quicker installation process. It also provides a very high level of protection, essentially making the product IP65 front and rear. This prevents dust, water, moisture or other elements from entering the panel. The fully front serviceable magnetic modules make it easy to service on the rare occasion you may need to do so.
Download the CAD drawings
| Specification | D1994SD | D2594SD | D3094SD | D4094SD |
|---|---|---|---|---|
|
Pixel Pitch |
1.9 mm |
2.5 mm |
3 mm |
4 mm |
|
LED Type |
SMD1515 |
SMD2121 |
SMD2121 |
SMD2121 |
|
Panel Dimension (W×H) |
512×256 px |
384×192 px |
320×160 px |
240×120 px |
|
Panel Resolution (W×H×D) |
37.8 in. x 18.9 in. / 960x480x61 mm |
|||
|
Pixel Density |
284,444/m² |
160,000/m² |
111,111/m² |
62,500/m² |
|
Panel Weight |
24.2 lbs |
|||
|
Avg. Power Consumption |
92 watts |
|||
|
Max. Power Consumption |
230 watts |
|||
|
Brightness |
800 nits |
|||
|
Refresh Rate |
3840Hz |
|||
|
Scan Mode |
Constant current driver (Compatible) |
|||
|
Gray Scale |
10-14Bit adjustment |
|||
|
Access |
Front access |
|||
|
Ingress Protection |
Front IP65 , Rear IP63 |
|||
|
Color Temperature |
2500K- 10000K adjustment |
|||
|
Working Temperature |
14°F~104°F |
|||
|
Storage Temperature |
-13°F~140°F |
|||
|
Working Humidity (RH) |
10% ~ 90% RH |
|||
|
LED Lifespan |
100,000 h |
|||
|
Working Voltage |
Wide ( AC:100V~240V, 50-60Hz) Or Narrow ( AC:200V~240V,50-60Hz) Optional |
|||
