Flyer Series
INDOOR LED
Overview
The Flyer Series was designed to make a large impact on a small scale. It offers a variety of features that make it ideal for a number of different applications. Everything from trade shows, to retail spaces, restaurants, way finding and more.
Size Available:1.97×5.9×1.64 ft (600x1800x500 mm)
- ARMOR COATING
- ENERGY EFFICIENT
- ULTRA LIGHT
- SMART MODULE
- FRONT ACCESS
- HIGH GRAY SCALE
- IP65
Patented Armor Coating
The Flyer Series features a patented armor coating technology. The surface of the LED module as well as the PCB board is completely sealed with an epoxy resin. This gives the product much more protection against collisions or other incidental contact. This technology also makes the LED modules waterproof, anti-static, and dust proof, making it ideal for high traffic areas and when moisture, oxidation, or other environmental factors could be an issue.
Infinity Edge
The armor coating allows us to extend the LED diodes to the edge of the LED modules creating an infinity edge display. This creates a more immersive experience, and allows you to place multiple units together to create a larger display.
Easy Installation & Maintenance
The Flyer Series is very lightweight and thin. It can be hung from above, wall mounted, or utilize a base with wheels, making it extremely mobile. The unit is very easy to service. The LED modules can simply be removed from the front with a magnetic tool, allowing you to quickly replace the modules if needed.
User-Friendly
The Flyer Series features a built in controller and content management system. The units can automatically recognize how and where they are setup. An app is included which allows you to remotely manage your content and make other screen adjustments. There is even a cloud software platform which allows you to manage multiple Flyers through a worldwide cloud network.
Built-In Audio
The Flyer Series features built-in speakers providing stereo sound. This makes it much simpler and streamlined to provide audio
when needed.
| Specification | F19618S | F25618S | ||
|---|---|---|---|---|
|
Pixel Pitch |
1.8 mm |
2.5 mm |
||
|
Panel Dimension (W×H×D) |
1.97x5.9x1.64 ft / 600x1800x500 mm |
|||
|
Panel Resolution (W×H) |
320×900 px |
240×675 px |
||
|
Panel Weight |
77.2 lbs (without base) |
|||
|
Avg. Power Consumption |
225 watts |
|||
|
Max Power Consumption |
450 watts |
|||
|
Brightness |
50-800CD/m² Adjustable |
|||
|
Refresh Rate |
2500K- 10000K Adjustable |
|||
|
Scan Mode |
Synchronous / Asynchronous |
|||
|
Color Temperature |
≤ 3840HZ |
|||
|
Viewing Angle |
140° |
|||
|
Access |
Front Access |
|||
|
Working Temperature |
-4°F - 122°F |
|||
|
Storage Temperature |
-4°F - 122°F |
|||
|
Working Humidity (RH) |
10%~ 90% RH |
|||
|
Power Supply |
AC90—264VAC, 47—63 HZ |
|||
|
Processing |
≤ 16 bit |
|||
|
Communication Mode |
WiFi, 4G |
|||
|
Operation System |
Windows / iOS / Android |
|||
