LED Video Walls
What Is an LED Video Wall?
An LED video wall is a modular display system built from seamlessly tiled LED panels — scalable to virtually any size, shape, and brightness level. Unlike traditional displays, there are no bezels breaking up the image. Just one continuous, high-resolution screen.
Firefly LED designs and builds video walls for churches, corporate spaces, live events, universities, retail environments, and more. Use our Screen Builder to configure your wall, see the actual dimensions, and get real specs — no sales call required.
Where LED Video Walls Make an Impact
LED video walls work across a wide range of environments. Here’s where Firefly LED customers are putting them to work.
House of Worship
From Sunday services to special events, LED video walls help congregations of all sizes deliver a more engaging experience. Crystal-clear visuals, easy content switching, and a look that scales with your space.
Corporate & Lobby Displays
First impressions matter. A video wall in your lobby, boardroom, or common area signals professionalism and keeps your brand front and center. We work with companies ranging from regional offices to Fortune 500 headquarters.
Events & Entertainment
Stage backdrops, festival screens, touring displays — LED video walls are built for the energy of live events. Modular panels mean fast setup, and mobile options mean your wall goes where the show goes.
Retail Displays
Draw attention, promote products, and create an experience that keeps shoppers engaged. Indoor and window-facing LED walls give retailers a dynamic alternative to static signage.
Higher Education
LED video walls have become the standard backdrop for film, broadcast, and live streaming. High refresh rates and accurate color reproduction make Firefly walls camera-ready out of the box.
Virtual Production
LED video walls have become the standard backdrop for film, broadcast, and live streaming. High refresh rates and accurate color reproduction make Firefly walls camera-ready out of the box.
Find the Right LED Video Wall
Indoor LED Video Walls
A Plus Series
A fine pitch indoor display built for close viewing in worship spaces and corporate environments.
Best For:
House of Worship, Corporate
Size(s):
1.97 × 1.10 × 0.11 ft
0.9, 1.2, 1.5, 1.8, 2.5 mm
A Pro Series
Firefly’s premier fine pitch indoor display, built for high-end corporate, retail, and broadcast installations.
Best For:
Corporate, Retail
Size(s):
1.97 × 1.11 × 0.14 ft
Pixel Pitch:
0.7, 0.9, 1.2, 1.5, 1.8 mm
C Series
A transparent LED display for storefronts, glass facades, and architectural installs where visibility through the screen matters.
Best For:
Retail, Trade Shows
Size(s):
3.28 × 9.84 × 0.28 ft
Pixel Pitch:
3.9×7.8 mm
M Series
A modular indoor panel built for mobility — fast to set up and tear down for touring, rental, and trade show use.
Best For:
Touring, Trade Shows
Size(s):
1.64 × 1.64 ft
Pixel Pitch:
2.6, 2.9, 3.9 mm
Y Series
A flexible panel that curves and bends. Built for custom shapes, wrapped backdrops, and installations where flat won’t work.
Best For:
Corporate, Custom
Size(s):
0.98 × 0.55, 1.18 × 0.59 ft.
Pixel Pitch:
0.9, 1.2, 1.5, 1.8, 2.5 mm
Outdoor LED Video Walls
O Series
Built for long-distance viewing. Scoreboards, outdoor advertising, and large venues where viewers are well back from the screen.
Best For:
Scoreboards, Advertising
Size(s):
3.15 × 3.15 × 0.26 ft
Pixel Pitch:
6.67, 8, 10 mm
OHD Series
Firefly’s premier outdoor display, with fine pitch options for installations where image quality matters.
Best For:
Restaurants, Advertising
Size(s):
1.57 x 1.77 ft.
Pixel Pitch:
1.2, 1.5, 1.9, 2.5 mm
M Series
A rugged mobile outdoor panel built for events, touring, and temporary installations that move from venue to venue.
Best For:
Touring, Events
Size(s):
1.64 × 1.64 ft
Pixel Pitch:
2.6, 2.9, 3.9 mm
How to Choose the Right LED Video Wall
Not sure where to start? These four factors will narrow it down fast.
Viewing Distance
The further your audience sits from the screen, the larger the pixel pitch you can use. Close-up environments like boardrooms or lobbies need a finer pitch for sharp detail. Large venues and outdoor displays can go coarser without sacrificing image quality.
Indoor vs. Outdoor
Outdoor displays need higher brightness levels to compete with sunlight, plus weather-resistant construction. Indoor displays prioritize color accuracy and fine pixel pitch for close viewing. Don’t use an indoor panel outside.
Pixel Pitch
Pixel pitch is the distance between LED clusters — smaller numbers mean higher resolution. A P1.5mm panel is ideal for a corporate lobby. A P6mm panel is built for a scoreboard. Use our pixel pitch guide to find your match.
Mobility
Will your display stay in one place, or does it need to move? Permanent installations have different mounting and power requirements than rental or touring setups. If your wall travels, the M Series is built for it.
Not sure which direction to go? Use the Screen Builder to configure your wall and see real specs before you commit — or contact us and we’ll help you figure it out.
LED Video Wall FAQs
What is an LED video wall, and how does it work?
An LED video wall is a large-scale display made up of multiple LED panels seamlessly joined together to create one continuous screen. Each panel consists of tiny LED lights that emit their own light, allowing for vibrant colors, deep contrast, and exceptional brightness. This modular design means you can customize the size and shape of your video wall, making it suitable for a wide range of applications, from retail and corporate settings to live events and control rooms.
What are the benefits of using an LED video wall compared to other display technologies?
LED video walls offer several advantages over other display technologies like LCD or projectors. They provide superior brightness, even in well-lit environments, and seamless visuals without the bezels found in traditional LCD displays. LED walls are highly durable, energy-efficient, and scalable to any size or shape, making them a versatile solution for both indoor and outdoor use. With a long lifespan and vibrant image quality, they’re a cost-effective choice for many industries.
Can LED video walls be used outdoors?
Yes, LED video walls are designed for both indoor and outdoor use. Outdoor LED video walls are built to withstand weather conditions such as rain, wind, and extreme temperatures. They are also equipped with high brightness levels to ensure clear visibility, even in direct sunlight. Firefly LED offers outdoor LED video walls that are durable and reliable, making them ideal for outdoor events, advertising, and public displays.
How do I choose the right pixel pitch for my LED video wall?
The pixel pitch of an LED video wall refers to the distance between the centers of two LED pixels. Choosing the right pixel pitch depends on how far viewers will be from the screen. For close-up viewing, like in retail or control rooms, a smaller pixel pitch is ideal for sharp details. For distant viewing, such as outdoor advertising, a larger pixel pitch can provide excellent visibility without unnecessary cost. Firefly LED can help you determine the best pixel pitch for your specific needs.
How much does an LED video wall cost?
LED video wall pricing varies based on pixel pitch, size, and whether the installation is indoor or outdoor. Entry-level configurations typically start in the range of $10,000–$20,000, with larger or fine pitch installations running higher. Firefly LED offers financing options to help spread the cost. Use the Screen Builder to get a real configuration and spec sheet, or contact us for a custom quote.
Does Firefly LED handle installation?
Yes. Firefly LED provides installation support and can connect you with certified installers for your project. Contact us to discuss your installation needs alongside your display order.
How long do LED video walls last?
LED video walls are built for longevity. Most commercial-grade panels are rated for 100,000 hours of use, which translates to well over a decade of regular operation. Firefly LED backs its displays with a manufacturer warranty — see our warranty page for full details.
Can LED video walls be customized to non-standard sizes or shapes?
Yes. Because LED video walls are modular by design, they can be configured to almost any size or aspect ratio. The Y Series also supports curved and flexible configurations for installations that require a non-flat surface. Use the Screen Builder to explore size options, or contact us for a fully custom solution.
